NeoCylinder Collection

The fresh design of the NeoCylinder pull is available in straight and offset versions.

1-1/4" tubing blends seamlessly into the terminating flat end posts.

NeoCylinder pulls are available with Rockwood's popular "GripZone" finish.

  • Designs
  • Specifications
  • Finishes
  • Downloads

RM7210 - straight pull





Close

RM7210 - straight pull

1-1/4" diameter

11", 16", 20", up to 36" CTC

2-3/4" projection

RM7212 - push bar





Close

RM7212 - push bar

1-1/4" diameter

11", 16", 20", up to 36" CTC

2-3/4" projection

RM7220 - offset pull





Close

RM7220 - offset pull

1-1/4" diameter

Specify CTC

2-3/4" projection

RM7230 - straight pull, GripZone





Close

RM7230 - straight pull, GripZone

1-1/4" diameter

11", 16", 20", up to 36" CTC

2-3/4" projection

RM7232 - push bar, GripZone





Close

RM7232 - push bar, GripZone

1-1/4" diameter

Specify CTC

2-3/4" projection

RM7240 - offset pull, GripZone





Close

RM7240 - offset pull, GripZone

1-1/4" diameter

11", 16", 20", up to 36" CTC

2-3/4" projection

BHMA 629





Close

BHMA 629

Bright Stainless Steel

BHMA 630





Close

BHMA 630

Satin Stainless Steel
